| 产品参数 | |||
|---|---|---|---|
| 品牌 | MERSEN | ||
| 额定电流 | 80A | ||
| 额定电压DC | 500V | ||
| 额外特性 | 快速熔断 | ||
| 封装/规格 | NH000GG50V80 | ||
| 包装 | 盒装 | ||
| 认证机构 | UL | ||
| 最小包装量 | 1 | ||
| 数量 | 5620 | ||
| 批号 | 24 | ||
| 封装 | MERSEN | ||
| 可售卖地 | 全国 | ||
| 型号 | Y216543 | ||
FERRAZ法雷国外采购熔断器Y216543H NH000GG50V80 NH 000 80A 500V GG
A080431J FD20GD150V25 CC1500 CP GRD 20 127 25
D600GB35C20QF Q089392
D600SE42C125QF H079495
NH000GG69V32 N228448
NH00AM69V100 G227867
W330023C DN000UB69V80V 6,9 URB 000 D08 V 080
P214626J FR22GG69V50 690V CP 22X58 GG 50A S/I FS
CMC101N
CUSCC2 K1062793
F322051C NH000GS69V50PV 6,9 GS 000 PV 050
DCT20-2
Y216543H NH000GG50V80 NH 000 80A 500V GG
S222978J FR22AM69V10P 690V CP 22X58 AM 10A P FS
LB203PSN
2000413.160
3002413.80
2047720.20
2063332.550
2063332.800
2041132.160
5011528.1
The NH system is classified among plug-in fuse systems and is composed of:
fuse-base (possibly including terminal covers and phase barriers)
fuse-link with blade contact
fuse-link replacement device (LV HRC fuse puller)
Since the design of this system cannot guarantee non-interchangeability of rated current it must be handled by a qualified professional.
Type "gG" NH fuse-links are full range breaking capacity fuse-links and are used to protect cables and equipment. They can interrupt any current surge, from the lowest fusing current up to their breaking capacity, and so can be used alone as protection. They also protect electrical devices and industrial set-ups from the electrodynamic effects of very high short-circuit currents.
Item Number
Y216543
Catalogue No.
NH000GG50V80
Description
DIN NH Standard fuse-link gG Size NH000 500VAC 250VDC 80A live tags Double indicator Body width 21mm
EAN/UPC Code
4086500083121
Rated voltage AC IEC
500 V
Rated voltage DC IEC
250 V
Ampere Rating
80 A
ROHS Compliant
Yes
AC or DC
AC/DC
Speed/Characteristic
gG
Fuse Size
NH000
Mounting
Clip
AC Max I.R./Breaking Capacity: I1
120 kA
Power Dissipation at Rated Current Value
6.5 W
