库伯勒kubler机电式预置型计数器数显多功能仪表7.130.A12.859.9451

技术数据（机械）
■ 小型空心轴电机编码器适合用于 BLDC，直流伺服和步进电机的反馈
■ 通孔空心轴 Φ6mm
■ 增量信号 A,B,N
■ 6 或 10 极换向信号可选
■ 与旋转变压器安装兼容
■ 分辨率可达 2048 ppr
■ 工作温度可达 120℃
■ 频率响应到 300kHz
■ 安装高度 22.4mm
尺寸 外径：可选 31.7mm；
高度：可达 22.5mm
轴径 6mm
法兰
（外壳的安装）
伺服法兰
空心轴公差 + 0.001"/ ~ 0.000"(+ 0.025mm/ ~ 0.000mm)
连接轴的径向跳动 ± 0.05mm 可选（包括轴与安装表面的垂直度）
连接轴的轴向跳动 ± 0.25mm （可选）
安装 1.045"(26.54mm) 弹性随动环
( 与尺寸 10 的旋转变压器兼容 )
加速度 100000rad/s2 可选
转动惯量 1.6gm-cm2
高转速 5 000 rpm （连续）
12 000 rpm （短时）
轴承寿命 [(3.6×109)/RPM] 小时；
例如：6 000RPM 时为 605 000 小时
工作温度 0℃ ~ +120℃
储存温度 0℃ ~ +120℃
相对湿度 90% 无冷凝
抗振动
(DIN EN 60068-2-6)
在 5 Hz ~ 2000Hz 时为 2.5g
抗冲击
(DIN EN 60068-2-27)
50g 持续时间 6ms
材料 外壳：铸铝
随动环：铝
轴套：黄铜，码盘：0.76mm 厚（玻璃）
重量 45g
连接 飞线
电机反馈系统 F18
交流同步和直流无刷电机 增量式474 编码器 计数器 指示器 继电器 打印机 切纸机
技术数据（电气）
尺寸图
